Entry-level three axis made from fully stress-relived structured steel for cutting and carving flat board. The Routers features • Precision ball scree drives • Rack and pinion transmission • Multi-zone vacuum plenum • World renown HIWIN bearings • Windows® based easy-to-learn and use G-Code Interface (multiple languages).
Applications3D Carving, Acrylic Fabrication, Aluminum Fabrication, Architectural Mill work, Cabinetry, Exhibits and Fixtures, Sign making, Arts and Crafts, Furniture, Boat Building, Musical Instruments and More.
Acrylic, ACM, Copper, Brass, Aluminum, PVC, MDF, Melamine plastic, Foam, Melamine, Phenoic, Plywood, HDPE, Solid Surface, Solid Wood, etc.
|
Entry-level
Woodworking
CNC Router Models
|
Traveling Area
(mm)
|
Cut Speed
(mm/min)
|
Frame |
G.W.
(kgs)
|
Packing Size
(mm)
|
||||
|
X |
Y |
Z |
L |
W |
H |
||||
| WW1212 |
1200 |
1200 |
200 |
25000 |
Welded Steel |
1100 |
2100 |
1800 |
1800 |
|
WW1313 |
1300 |
1300 |
200 |
25000 |
Welded Steel |
1200 |
2200 |
1900 |
1900 |
|
WW1325 |
1300 |
2500 |
200 |
25000 |
Welded Steel |
1650 |
3200 |
2200 |
1900 |
|
WW1325H |
1300 |
2500 |
400 |
25000 |
Welded Steel |
1700 |
3200 |
2200 |
2200 |
|
WW1530 |
1500 |
3000 |
200 |
25000 |
Welded Steel |
1950 |
6800 |
2200 |
1900 |
|
WW2030 |
2000 |
3000 |
200 |
25000 |
Welded Steel |
2250 |
3800 |
2200 |
1900 |
|
WW2525 |
2500 |
2500 |
200 |
25000 |
Welded Steel |
2400 |
3300 |
3000 |
1900 |
|
WW2040 |
2000 |
4000 |
200 |
25000 |
Welded Steel |
2700 |
4800 |
2200 |
1900 |
|
WW2550 |
2500 |
5000 |
300 |
25000 |
Welded Steel |
3100 |
6100 |
3000 |
1900 |
|
Options |
Full range of tables sizes
4’(1300mm) X 4’(1300mm) to 10’(3000mm) X 20’(6000mm)
|
||||||||
| Vacuum pumps for easy part fixturing | |||||||||
| Wide range of spindle options 2HP(1.5KW) to 10 HP(7KW) | |||||||||
| Digital AC servo for high-speed/acceleration cutting | |||||||||
| Coolant mist systems for non-ferrous metal cutting | |||||||||
| Rotary for carving cylinder | |||||||||
| Dust collector for collecting clastic during processing to product rails and spindle | |||||||||
| Ncstudio/Mach3/ Syntec/ Siemens control system, etc. | |||||||||
1. Spindle
1.1 Manual Change Spindle
Italian HSD Air Cooling Spindle
Domestic Air Cooling Spindle
Domestic Water Cooling Spindle
Italian Colombo Air Cooling Spindle
1.2. ATC Spindle
Chinese CS ATC Air Cooling Spindle
Italian HSD ATC Air Cooling Spindle
Chinese ATC Water Cooling Spindle
Italian HSD 5axis ATC Water Cooling Spindle
Italian HSD ATC Water Cooling Spindle
Italian Hiteco ATC Air Cooling Spindle
2. Motor
Fuxing Stepper Motor
Taiwan Delta Servo Motor
Japanese Panasonic Servo Motor
Japanese Yaskawa Servo Motor
Japanese Fanuc Servo Motor
France Siemens Servo Motor
Taiwan Apex Reducer
Japanese Shimpo Reducer
3. Control System
Rich Auto DSP Controller
Ncstudio DSP Controller
Ncstudio Software Controller
Mach3 Software Controller
France Siemens Controller
Taiwan Syntec Controller
Japanese Fanuc Controller
Italian Osai Controller
4. Inverter
Fuling Inverter
Taiwan Delta Inverter
Japanese Omron Inverter
France Schneider Contactor
France Schneider Main Switch
Japanese Omron 24V Power Supply
Japanese Omron Limit Sensor
Japanese Omron Power Switch
Taiwan HIWIN Square Rails
Taiwan TBI Ball Screw
High Precision Helical Rack Gear 1.25mol
LanPu Transformer
High Quality Auto Lubrication System
Good Quality High-rise Flexible Wire
Hard Rubber Limited
Protect Fuses
Vacuum & T-slot Combined Table
High-quality Belt
Options
Rotary-Removable Type
Rotary-At the End of Machine
Rotary-On the Side of Machine
Germany SCHMLAZ Vacuum Beam
Stainless Steel Water Slot
Linear Tool Magazine
Carrousel Tool Magazine
Tool Sensor System
Water Chiller
Air Compressor
Germany Becker Vacuum Pump
Chinese Water Cooling Pump
TY Air Cooling Pump
Snail Air Cooling Vacuum Pump
Italian HSD Boring Unit
Mist Cooling System
Dust Collector
Hand Wheel
Material Alignment System
1. The machine is guaranteed for 12 months.
2. Technical support by phone, e-mail or MSN around the clock.
3. Friendly English version manual and operation video CD disk.
