Stone Carving Machine

Stone Carving Machine
Inquriy
0.0


Specifications

Stone Carving Machine is suitable for Curb & Paving Stone Forming industries, Stone processing factories, Tombstone processing industries, Advertisement industries for Stone art craft works, Home & Outdoor Product making industries, Architectural decoration industries and so on.

1.Profiled steel welded lathe bed stabilizing treated under high temperature to ensure excellent rigidity and vigorous strength within minimum distortion,.

2.Precise traveling of Y axis driven by double motor ensures stable performance of machine.

3.High precision rack and pinion transmission ensures high accuracy, fast speed and strong power.

4.Imported square linear guide rail ensures high accuracy, heavy work load and long service time.

5.Top-quality mechanical and electric all design with well-selected brand components minimize breakdown rate.

6.Configured with water tank and automatic cooling water supply system.

7.Overall dust-proof and water-proof design protects all moving.

Performance Parameter
Number
Description
Parameter
1
X,Y,Z Working Area
1300x2500x200mm
2
Table Size
1360×2940mm
3
X,Y,Z Traveling Positioning Accuracy
±0.03/300mm
4
X,Y,Z Repositioning Accuracy
±0.03mm
5
Frame
Welded Structure
6
X, Y Structure
Rack and Pinion Drive, Hiwin Rail Linear Bearings
7
Z Structure
Hiwin Rail Linear Bearings and Ball Screw
8
Max. Engraving Speed
30000mm/min
9
Collect
3.175, 6, 12.7mm
10
Drive Motors
Stepper System
11
Working Voltage
AC380V/50/60Hz,3PH (Option: 220V)
12
Command Language
G Code
13
Operating System
DSP System (options: Ncstudio/Mach3 PC Software)
14
Computer Interface
USB
15
Flash Memory
128M(U Disk)
16
X,Y Resolution
<0.03mm
17
Software Compatibility
Type3/UcancameV9 Software (Option: Artcam software)
18
Running Environment Temperature
0 - 45 Centigrade
19
Relative Humidity
30% - 75%
20
Packing Size
3200X1960X1870mm
Sample

Machine Schematic

1. Spindle

1.1 Manual Change Spindle

  • MADE IN CHINA 5 AXIS CNC ROUTER

    Italian HSD Air Cooling Spindle

  • GOOD

    Domestic Air Cooling Spindle

  • CHEAP 5 AXIS CNC ROUTER

    Domestic Water Cooling Spindle

  • WATER COOLING SPINDLE 5 AXIS CNC ROUTER

    Italian Colombo Air Cooling Spindle

1.2. ATC Spindle

  • 5 AXIS CNC ROUTER

    Chinese CS ATC Air Cooling Spindle

  • European Quality 5 AXIS CNC ROUTER

    Italian HSD ATC Air Cooling Spindle

  •  5 AXIS CNC ROUTER FOR FOAM, ACRYLIC, SOFT WOOD, MDF, PLYWOOD

    Chinese ATC Water Cooling Spindle

  •  5 AXIS CNC ROUTER FOR WOODWORKING

    Italian HSD 5axis ATC Water Cooling Spindle

  •  5 AXIS CNC ROUTER FOR ADVERTISING

    Italian HSD ATC Water Cooling Spindle

  •  5 AXIS CNC ROUTER FOR CABINET

    Italian Hiteco ATC Air Cooling Spindle

2. Motor

  •  5 AXIS CNC ROUTER FOR FURNITURE

    Fuxing Stepper Motor

  •  5 AXIS CNC ROUTER FOR GUITAR MAKING

    Taiwan Delta Servo Motor

  •  5 AXIS CNC ROUTER FOR PROCESSSING THE DOOR

    Japanese Panasonic Servo Motor

  •  5 AXIS CNC ROUTER FOR CUTTING WOOD

    Japanese Yaskawa Servo Motor

  • HIGH QUALITY 5 AXIS CNC ROUTER

    Japanese Fanuc Servo Motor

  •  5 AXIS CNC ROUTER FOR ENGRAVING WOOD

    France Siemens Servo Motor

  •  5 AXIS CNC ROUTER FOR DOOR AND WINDOWS

    Taiwan Apex Reducer

  •  5 AXIS CNC ROUTER FOR CARVING WOOD

    Japanese Shimpo Reducer

3. Control System

  •  5 AXIS CNC ROUTER FOR 3D CARVING

    Rich Auto DSP Controller

  •  5 AXIS CNC ROUTER FOR 3D ENGRAVING

    Ncstudio DSP Controller

  •  5 AXIS CNC ROUTER FOR ART AND CRAFT

    Ncstudio Software Controller

  •  5 AXIS CNC ROUTER FOR STONE CARVING

    Mach3 Software Controller

  •  5 AXIS CNC ROUTER FOR STONE ENGRAVING

    France Siemens Controller

  •  5 AXIS CNC ROUTER FOR MARBLE ENGRAVING

    Taiwan Syntec Controller

  •  5 AXIS CNC ROUTER FOR GRANITE ENGRAVING

    Japanese Fanuc Controller

  •  5 AXIS CNC ROUTER FOR WOOD

    Italian Osai Controller

4. Inverter

  •  5 AXIS CNC ROUTER FOR PLYWOOD

    Fuling Inverter

  •  5 AXIS CNC ROUTER FOR MDF

    Taiwan Delta Inverter

  •  5 AXIS CNC ROUTER FOR PVC

    Japanese Omron Inverter

Basic Accessories
  •  5 AXIS CNC ROUTER’S SCHNEIDER CONTACTOR

    France Schneider Contactor

  •  5 AXIS CNC ROUTER’S SCHNEIDER MAIN SWITCH

    France Schneider Main Switch

  •  5 AXIS CNC ROUTER’S OMRON 24V POWER SUPPLY

    Japanese Omron 24V Power Supply

  •  5 AXIS CNC ROUTER’S OMRON LIMIT SENSOR

    Japanese Omron Limit Sensor

  •  5 AXIS CNC ROUTER’S OMRON POWER SWITCH

    Japanese Omron Power Switch

  •  5 AXIS CNC ROUTER’S HIWIN SQUARE RAILS

    Taiwan HIWIN Square Rails

  •  5 AXIS CNC ROUTER’S TAIWAN TBI BALL SCREW

    Taiwan TBI Ball Screw

  •  5 AXIS CNC ROUTER’S 1.25MOL HIGH PRECISION HELICAL RACK GEAR

    High Precision Helical Rack Gear 1.25mol

  •  5 AXIS CNC ROUTER’S LANPU TRANSFORMER

    LanPu Transformer

  •  5 AXIS CNC ROUTER’S AUTOMATIC LUBRICATION SYSTEM

    High Quality Auto Lubrication System

  • 5 AXIS CNC ROUTER’S HIGH-RISE FLEXIBLE WIRE

    Good Quality High-rise Flexible Wire

  • 5 AXIS CNC ROUTER’S HARD RUBBER LIMITED

    Hard Rubber Limited

  • 5 AXIS CNC ROUTER’S PROTECT FUSES

    Protect Fuses

  • 5 AXIS CNC ROUTER’S VACUUM TABLE

    Vacuum & T-slot Combined Table

  • 5 AXIS CNC ROUTER’S HIGH QUALITY BELT

    High-quality Belt

Options

  • 5 AXIS CNC ROUTER’S ROTARY-RAMOVABLE TYPE

    Rotary-Removable Type

  • 5 AXIS CNC ROUTER’S ROTARY-AT THE END OF MACHINE

    Rotary-At the End of Machine

  • 5 AXIS CNC ROUTER’S ROTARY-ON THE SIDE OF MACHINE

    Rotary-On the Side of Machine

  • Germany SCHMLAZ Vacuum Beam

  • Stainless Steel Water Slot

  • Linear Tool Magazine

  • Carrousel Tool Magazine

  • Tool Sensor System

  • Water Chiller

  • Air Compressor

  • Germany Becker Vacuum Pump

  • Chinese Water Cooling Pump

  • TY Air Cooling Pump

  • Snail Air Cooling Vacuum Pump

  • Italian HSD Boring Unit

  • Mist Cooling System

  • Dust Collector

  • Hand Wheel

  • Material Alignment System

Guarantee & After Sales Service

1. The machine is guaranteed for 12 months.

2. Technical support by phone, e-mail or MSN around the clock.

3. Friendly English version manual and operation video CD disk.
